GD32C2x1系列
-
概述
-
产品组合
-
产品选择器
-
文档
概述
GD32C2x1系列MCU在坚持优异价钱竞争力的同时，，，，，，，，显著提升运算性能与外设规格，，，，，，，，实现超高性价比升级 。。。。。该系列接纳Arm先进的Cortex?-M23内核架构，，，，，，，，性能比 Cortex? M0+ 提高10%，，，，，，，，主频可达48MHz，，，，，，，，具备单周期乘法和整数除法运算等高效处置惩罚能力，，，，，，，，大幅提升软件执行效率 。。。。。存储设置方面，，，，，，，，搭载32KB~64KB高可靠嵌入式Flash和12KB低功耗SRAM，，，，，，，，全存储区域均配备ECC纠错功效 。。。。。为知足差别应用场景需求，，，，，，，，提供TSSOP20/LGA20，，，，，，，，QFN28，，，，，，，，LQFP32/QFN32以及LQFP48 /QFN48等多种封装选择 。。。。。
GD32C2x1系列MCU提供多达4个通用16位准时器、1个16位高级准时器 。。。。。配备2路高速SPI接口（支持四线QSPI模式，，，，，，，，速率达24Mbps）、2路I2C接口（支持Fast Mode+，，，，，，，，速率1Mbit/s）和3路UART（速率6Mbps），，，，，，，，集成3路DMA控制器，，，，，，，，1路I2S，，，，，，，，确保高效通讯能力 。。。。。很是适合应用在小家电、白电、BMS电池管理系统、小型显示装备、便携式消耗电子产品、工业辅助控制系统以及车载后装装备等场景 。。。。。
探索今年会官网登录入口产品组合
-
接纳Cortex?-M23内核，，，，，，，，主频达48MHz 存储容量支持32KB~64KB Flash和12KB SRAM
产品选择器
14条效果
|
Part No.
|
Core
|
Series
|
Package
TSSOP20
QFN48
QFN32
QFN28
LQFP48
LQFP32
LGA20
|
Max Speed (MHz)
|
Flash (Bytes)
32K
64K
|
SRAM (Bytes)
|
I/O
18
26
30
45
|
GPTM (32bit)
|
GPTM (16bit)
|
Advanced TM (16bit)
|
HRTM
|
Basic TM (64bit)
|
Basic TM (32bit)
|
Basic TM (16bit)
|
LPTM (32bit)
|
LPTM (16bit)
|
SysTick (64bit)
|
SysTick (24bit)
|
WDG
|
RTC
|
USART+UART
2
3
|
LPUART
|
I2C
|
QSPI
|
SPI
|
I2S
|
CAN 2.0B
|
USB 2.0
|
Ethernet
|
SDIO
|
EtherCAT Slave Controller
|
MFCOM
|
LIN
|
LCD-TFT
|
Segment LCD
|
Camera
|
IPA
|
SAI
|
TMU
|
EXMC
|
CEC
|
14bit ADC Units (CHs)
|
12bit ADC Units (CHs)
1(9)
1(13)
1(12)
1(11)
|
12bit DAC Units
|
Comp
|
IEEE 802.11
|
Bluetooth
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cortex?-M23 | GD32C231 | LQFP48 | 48 | 32K | 12K | 45 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | LQFP48 | 48 | 64K | 12K | 45 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | QFN48 | 48 | 32K | 12K | 45 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | QFN48 | 48 | 64K | 12K | 45 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(13) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | LQFP32 | 48 | 32K | 12K | 30 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | LQFP32 | 48 | 64K | 12K | 30 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | QFN32 | 48 | 32K | 12K | 30 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | QFN32 | 48 | 64K | 12K | 30 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 3 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(12) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | QFN28 | 48 | 32K | 12K | 26 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(11) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | QFN28 | 48 | 64K | 12K | 26 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(11) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | TSSOP20 | 48 | 32K | 12K | 18 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | TSSOP20 | 48 | 64K | 12K | 18 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | LGA20 | 48 | 32K | 12K | 18 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 | |
| Cortex?-M23 | GD32C231 | LGA20 | 48 | 64K | 12K | 18 | 0 | 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 2 | 0 | 2 | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 2 | 0 | 0 |
