产品选择器
5 个效果
Loading
|
Part No
|
Core
|
Max Speed (MHz)
|
Flash (KB)
|
RAM (KB)
|
I/O
|
DIV
|
Advanced TMR
|
GPTM
|
WDG
|
RTC
|
UART
|
USART
|
I?C
|
SPI
|
CAN
|
ADC (1Msps, 12bit)*
|
DAC
|
CMP
|
PGA
|
Integrated three half-bridge gate driver
|
Pin Counts
|
Package
|
Temperature Operating Range (°C)
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cortex-M0 | 64 | 32 | 4 | 22 | √ | 1 | 4 | 1 | N | 1 | 0 | 1 | 1 | 0 | 1, 12ch | 1(5bit) | 2 | 2 | No | 24 | SSOP | -40~105 | |
| Cortex-M0 | 64 | 32 | 4 | 30 | √ | 1 | 4 | 1 | N | 1 | 0 | 1 | 1 | 0 | 1, 15ch | 1(5bit) | 2 | 2 | No | 32 | LQFP | -40~105 | |
| Cortex-M0 | 64 | 32 | 4 | 20 | √ | 1 | 4 | 1 | N | 1 | 0 | 1 | 1 | 0 | 1, 12ch | 1(5bit) | 2 | 2 | 6N/120V | 40 | QFN | -40~105 | |
| Cortex-M33 | 180 | 512 | 128 | 62 | √ | 2 | 13 | 2 | 1 | 2 | 3 | 2 | 3 | 3 | 3,16ch | 3(12bit) | 3 | 0 | 6N/150V | 88 | QFN | -40~105 | |
| Cortex-M0 | 64 | 32 | 4 | 10 | 1 | 1 | 3 | 1 | 0 | 1 | 0 | 1 | 1 | 0 | 1 | 1 | 2 | 2 | 2N 600V PreDriver | 28 | TSSOP28 | -40~105 |
